Overall Length (m) : 55
Beam (m) : 22.8
Draft (m) : 2.3
Excavator Model : Hitachi EX 5600
Excavator Power (kW) : 2 × 1119
Dredging Depth (m) : 11 / 16 / 19
Bucket Capacity (m³) : 8 / 16 / 22
Propulsion Power (kW) : No propulsion (non-self-propelled)
Construction Completion Date : 2021
Applications
Coastal port & navigation channel dredging
Harbor basin, waterway & berth excavation
Rock & hard soil dredging (backhoe mode)
Coastal Reclamation & land preparation
Small‑scale marine foundation dredging
Nearshore sediment clearing & silt removal
Played a key role in the construction of the Pinglu Canal in Guangxi
Advantages
Heavy‑duty EX3600 backhoe with 22m³ large bucket for high efficiency
Ultra‑strong digging force: 1050kN bucket force / 951kN arm force
Great working range: max depth 8.63m, max reach 18.24m
Wide beam (20.8m) & shallow draft (2.1m) for excellent stability
Flexible 360° full‑slewing operation for precise dredging
Reliable power system: 90kW + 30kW generator sets
Complete CCS class & coastal certificate, ready to work
Full set fire‑fighting & lifesaving equipment compliant with regulations
Six ballast tanks for flexible trim & stability control
Compact layout, easy operation & low maintenance cost
