Construction Year: 2009
Length o.a.: 101.8m
Moulded Breadth: 18.2m
Moulded Depth: 5.2m
Average Draught: 3.5m
Dredging Capacity: 4000m³/h
Maximum Dredging Depth: 26m
Diameter of Suction Pipe: 850mm
Diameter of Discharge Pipe: 850mm
Vessel Type: Non-self-propelled Cutter Suction Dredger
Navigation Area: Coastal Service
High Efficiency: 4000m³/h large dredging capacity, suitable for large-scale Dredging Projects and improves construction efficiency sharply.
Wide Working Range: 26m maximum dredging depth meets deepwater dredging demands, adapting to various coastal working conditions.
Stable Dredging Performance: Equipped with large-caliber suction and discharge pipes, ensuring smooth mud and sediment delivery, less blockage.
Sturdy Structure: Reasonable hull size and solid steel structure, suitable for long-term coastal operation, low failure rate.
Cost-effective: Non-self-propelled design lowers daily maintenance and operating costs, easy to deploy and manage.
Port & Channel Dredging: Deepen and widen coastal ports and navigation channels, clear silt and sediment, keep channels unobstructed.
Waterway Maintenance: Carry out routine dredging work for coastal waterways, prevent siltation and ensure navigation safety.
Land Reclamation: Supply dredged sediment for coastal reclamation projects, support offshore engineering construction.
River Estuary Regulation: Clean up sediment at river estuaries, improve water flow condition and marine ecological environment.
Offshore Engineering Support: Assist in wharf construction, seawall building and other coastal infrastructure projects.
Vessel Type: Non-Self-propelled Cutter Suction Dredger
Navigation Area: Coastal Service
